Pendant Mount Installation
Package Contents
Ensure the dome camera package contains the following:
l
Avigilon H6SL Dome Camera (Indoor models)
o
T20 Pin-In star-shaped driver
o
Cable entry grommet
o
Provided accessories that are not required for this installation:
n
Mounting template sticker
n
4 screws and anchors for solid walls
n
Surface mount adapter
n
Side conduit cover
l
Avigilon H6SL Dome Camera (Environmental models)
o
T20 Pin-In star-shaped driver
o
Provided accessories that are not required for this installation:
n
Mounting template sticker
n
4 screws and anchors for solid walls
n
Surface mount adapter
n
Side conduit cover
n
1/2" Side conduit plate
Note: The NPT pipe (for pendant pipe mounted installations) and NPT-female to NPT-female adapter
(for pendant pipe and wall mounted installations) are not supplied by Avigilon and should be sourced
separately. However, if you are using the NPT adapter (H6SL-MT-NPTA1), the lock nut is included.
Ensure the NPT adapter (H6SL-MT-NPTA1) package contains the following:
l
NPT adapter for the H6SL Dome Camera
l
T20 Pin-In star-shaped driver
l
Lock nut
l
Teflon sealing tape
If you are also installing the pendant wall mount (CM-MT-WALL1), ensure the package contains the following:
