l
Pendant wall mount
l
8 screws
l
1 1/2" NPT to 3/4" NPT adapter
l
3/4" NPT nut
l
Wall mount gasket
Installation Steps
Complete the following sections to install the device.
Mounting the Dome Camera to a Pipe
If the dome camera needs to be installed to a pipe for a pendant installation, you can discard the surface
mount adapter that is provided with the dome camera and use the NPT adapter.
Note: This procedure requires a 1-1/2" NPT-female to NPT-female pipe adapter. It is recommended
that the NPT adapter be mounted to a 1-1/2" conduit pipe.
1. Pull the required cables through the NPT conduit pipe.
2. Apply thread seal tape to the pipe and screw on the 1-1/2" NPT female to NPT female pipe adapter.
3. Screw the lock nut onto the NPT adapter.
4. Apply thread seal tape to the NPT adapter and screw it into the pipe adapter.
Make sure the parts are assembled in this order from NPT conduit pipe to camera adapter:
a. NPT conduit pipe
b. 1-1/2" NPT female to female pipe adapter
c. Lock nut
d. NPT adapter
Installation Steps 32
