Overview
Camera Base Front View
1.
IRIlluminator
Provides scene illumination in the IRspectrum.
Only available on IR models.
2.
Ethernet port
Accepts power and Ethernet connection to the network. Server communication and image data
transmission also occur over this connection.
3.
Link LED indicator
Amber LED indicates if there is an active connection in the Ethernet port.
4.
Connection status LED indicator
Green LED provides information about device operation. For more information, see Connection Status
LED Indicator on page48.
5.
microSD card slot
Accepts a microSD card for onboard storage. For more information, see (Optional) Configuring
microSD Card Storage on page43.
Overview 8
