58
A360 P
e r s o n A l Mi x e r Us e r GU i d e
Parallel Connections
An A-Net distributor simplifies the connection or expansion of an existing Pro16 personal mixing system
with A360 Personal Mixers. As with the daisy chained system, a single analog input module or digital
console card is used to generate a 16-channel A-Net signal that is distributed to the Personal Mixers.
Using one or more A-Net distributors allows any number of A360 Personal Mixers to be integrated into a
personal mixing system along with A-16II and A-16R Personal Mixers. As with the daisy chain system, the
rear-panel mode switch on the A360 should be set to Pr o 16 when it is used with a Pro16 personal mixing
system made up of 16 or fewer input channels.
Analog input module or
digital console card
An A-Net distributor allows Personal Mixers to be connected in parallel.
The A360 Personal Mixer can be powered over the Cat-5 cable when connected to an A-Net distributor.
