Specifications
Audio Outputs
1/4” TRS stereo, headphone or line level;
1/8” TRS stereo, headphone or line level;
XLR balanced mono, line level
Stereo Mix Outputs,
Headphone/Line
Tip: Audio Left; Ring: Audio Right;
Sleeve: Ground
Mono Mix Output
Pin 2: Hot, Pin 3: Cold; Pin 1: Ground; impedance balanced
A-Net I/O
1 A-Net In, Neutrik EtherCon RJ45 connector;
Supports Pro16 and Pro16e
D/A Conversion
44.1/48kHz, 24-bit
Stereo Operation
Stereo Link, per channel pair;
Set at the input module;
Variable pan per mono channel or pan/spread per stereo
channel pair
USB Storage
Save/load mix configuration data, mix presets; firmware
updates
Headphone Output
1.0 watt maximum at 100 ohms
divided between both channels
Headphone Output
Impedance
32 ohms
Line Output Impedance
226 ohms
Freq. Response
2-22kHz +0.2dB/-3dB
THD +N
< 0.003%
Signal to Noise
(unweighted)
-106dB (measured with zero data into all channels)
Latency
0.880 msec (measured from analog input to analog output)
A-Net Cables Use unshielded Cat-5e UTP (or better) cable
A-Net Cable Length 400 feet (122 m)
A-Net Pro16e Protocol
Supports original Pro16 16-channel data;
Supports Power Over A-Net
Optional Power Supply
Input Voltage
Output Voltage
Plug Size
External, DC, universal switching type
100-240 volts, 50/60Hz
24 VDC, 0.5 amp
2 mm
Dimensions
11” (279.4 mm) wide x 6.9” (175.26 mm) deep;
1.835” (46.61 mm) high
Weight 3.4 lb. (1.54 kg)
Options
MT-1a Mic Stand Mount (uses 6-32 1/4-inch screws);
EB-1 Extension Bracket;
PS-120 Power Supply
