61
A360 P
e r s o n A l Mi x e r Us e r GU i d e
A-16D P
RO
A-16D P
RO
AN-16/i v.2
AN-16/i v.2
AN-16/i v.2
AN-16/i v.2
A-16
II
Aviom16/o-Y1
Listen through your choice of...
up to 32 channels distributed
to all Personal Mixers
up to 32 channels distributed
to all Personal Mixers
Channels 1-16Channels 1-16
Channels 17-32Channels 17-32
Channels 33-48Channels 33-48
Channels 49-64Channels 49-64
to additional
Personal Mixers
Select A360 mix channels from all
64 network channels (
CUSTOM mode)
Select A360 mix channels from all
64 network channels (CUSTOM mode)
A-16IIs and A-16Rs
utilize Channels
1-16 only
A-16IIs and A-16Rs
utilize Channels
1-16 only
to additional
Personal Mixers
to additional
Personal Mixers
A 64-input system using two A-Net distributors is shown.
A-16II or A-16R Personal Mixers may be used in a Pro16e-based system, but note that they can only access
the first 16 network slots.
