MSC SM2S-IMX8MINI 58 / 87
User Manual
7 Board Support Package (BSP)
7.1 General information
MSC-LDK and the underlying NXP release are based on the Yocto build system (https://yoctoproject.org).
The current MSC-LDK and the msc-sm2s-imx8mm BSP base on NXP’s Release L4.19.35_1.1.0.
7.2 MSC-LDK (Yocto)
7.2.1 MSC-LDK Terms
• The Yocto-based MSC-LDK uses a sophisticated approach to generate Linux images.
• A target is the hardware or CPU module on which the generated Linux software is to be run.
• An image contains all the files necessary for execution by the targeted hardware, e.g. the Linux kernel and the root filesystem.
• Software that is part of a Linux image is called a package.
• A package is generated from sources by a recipe, which is a description of where to download the sources and how to compile them within
Yocto.
• A layer is a collection of recipes. They are stackable and can extend or modify recipes defined in other layers. A BSP provides the necessary
layers to MSC-LDK to support the target’s hardware.
• MSC-LDK is mainly an installer of Yocto, MSC specific layers and BSP layers.
7.2.2 Getting Started
7.2.2.1 System requirements
• 64bit Linux x86 development host with at least 8GB of RAM - 16GB or more recommended
• Ubuntu 16.04 (LTS) or newer, other distributions may also work.
• Internet access for downloading packages (HTTP, FTP, Git and SSH).
• Lots of free disk space for the initial build (>128 GB)
• Python3 with ’pip’ installed (at least Python v3.3).
