Avnet SMARC MSC SM2S-IMX8MINI User Manual

MSC SM2S-IMX8MINI 32 / 87
User Manual
Signal
Option
Availability
Pin Type
Signal Level
Pin on
i.MX8M
Mini
Pin name on
i.MX8M Mini
Power
Tolerance
PU/PD
Description
USB3_EN_OC#
1
I/O OD
3.3V CMOS
n.a.
n.a.
3.3V
PU 10k
3.3V
Multi-function signal for enabling
USB power and indicating an over-
current event.
*
USB4_EN_OC#
1
I/O OD
3.3V CMOS
n.a.
n.a.
3.3V
PU 10k
3.3V
Multi-function signal for enabling
USB power and indicating an over-
current event.
*
*
NOTE: Module pulls USB[0:4]_EN_OC# low to disable USB power delivery on carrier board. Carrier board pulls the signal low to indicate over-current situation. If over-current
monitoring is desired, an OD driver should be implemented. In case no power switches are used, USB[0:4]_EN_OC# should be left unconnected.
4.5 Camera
MIPI CSI-2 interface is supported on CSI0 with 2 lanes or on CSI1 with 4 lanes, mutually exclusive assembly option.
Table 10: HDMI Signal Description
Signal
Pin
Type
Signal Level
Pin on
i.MX8M Mini
Pin name on
i.MX8M Mini
Power
Tolerance
PU/PD
Description
CSI0_RX[0]-
CSI0_RX[0]+
I
1.8V CMOS
A14
B14
MIPI_CSI_D0_N
MIPI_CSI_D0_P
1.8V
CSI differential data inputs
CSI0_RX[1]-
CSI0_RX[1]+
I
1.8V CMOS
A15
B15
MIPI_CSI_D1_N
MIPI_CSI_D1_P
1.8V
CSI differential data inputs
CSI1_RX[0]-
CSI1_RX[0]+
I
1.8V CMOS
A14
B14
MIPI_CSI_D0_N
MIPI_CSI_D0_P
1.8V
CSI differential data inputs
CSI1_RX[1]-
CSI1_RX[1]+
I
1.8V CMOS
A15
B15
MIPI_CSI_D1_N
MIPI_CSI_D1_P
1.8V
CSI differential data inputs
CSI1_RX[2]-
CSI1_RX[2]+
I
1.8V CMOS
A17
B17
MIPI_CSI_D2_N
MIPI_CSI_D2_P
1.8V
CSI differential data inputs
CSI1_RX[3]-
CSI1_RX[3]+
I
1.8V CMOS
A18
B18
MIPI_CSI_D3_N
MIPI_CSI_D3_P
1.8V
CSI differential data inputs
