5.3 Memory
5.3.1 SDRAM
The DDR Controller supports 32/16-bit LPDDR4-3000.
MSC SM2S-IMX8MINI SMARC™ modules use one physical rank with up to 4GByte SDRAM.
Table 22: Available SDRAM options
CPU
Bus Width
Memory Size
Memory
Organisation
i.MX8M Mini Solo, Dual
and Quad
64-bit Interface
1 GB
2x 32Mx16x8B
64-bit Interface
2 GB
4x 32Mx16x8B
64-bit Interface
4 GB
4x 64Mx16x8B
5.3.2 eMMC
Up to 64GB eMMC are supported. The eMMC is used in 8 bit mode.
Table 23: Available eMMC devices
Memory Size
Technology
Operating Temperature
Chip Identification
Extended
8 GB
15nm X2 eMLC
-25°C to +85°C
SDINBDG4-8G-I1
16 GB
15nm X2 eMLC
-25°C to +85°C
SDINBDG4-16G-I1
32 GB
15nm X2 eMLC
-25°C to +85°C
SDINBDG4-32G-I1
64 GB
15nm X2 eMLC
-25°C to +85°C
SDINBDG4-64G-I1
Industrial
