MSC SM2S-IMX8MINI 56 / 87
User Manual
6 Bus and Address Mapping
6.1 I²C Devices
Table 24: I²C Interfaces Overview
CPU Interface
Device
SMARC Connector
7-bit Address
I2C1
TPM
0x2E
PMIC1
0x31
PMIC2
0x33
Temp. Sensor
0x71
RTC
0x32
PCIe Clock Generator
0x6B
I2C2
I2C_PM
I2C3
Serial EEProm
I2C_GP
0x50
I2C4
I2C_LCD
GPIO
I2C_CAM0
*
I2C_CAM1
*
*
NOTE: CAM0 and CAM1 are GPIO based (bit-banged) and share the same I2C interface.
