3 Module Connector Pinout
The pinout of the module connector is based on the SMARC™ specification[1].
Table 5: Module Connector Pinout
Primary (Top) Side
Secondary (Bottom) Side
P1
SMB_ALERT_1V8#
S1
I2C_CAM1_CK
P2
GND
S2
I2C_CAM1_DAT
P3
CSI1_CK+
S3
GND
P4
CSI1_CK-
S4
NC
P5
NC
S5
I2C_CAM0_CK
P6
GBE0_SDP
S6
CAM_MCK
P7
CSI1_RX0+
S7
I2C_CAM0_DAT
P8
CSI1_RX0-
S8
CSI0_CK+
P9
GND
S9
CSI0_CK-
P10
CSI1_RX1+
S10
GND
P11
CSI1_RX1-
S11
CSI0_RX0+
P12
GND
S12
CSI0_RX0-
P13
CSI1_RX2+
S13
GND
P14
CSI1_RX2-
S14
CSI0_RX1+
P15
GND
S15
CSI0_RX1-
P16
CSI1_RX3+
S16
GND
P17
CSI1_RX3-
S17
GBE1_MDI0+
Primary (Top) Side
Secondary (Bottom) Side
P18
GND
S18
GBE1_MDI0-
P19
GBE0_MDI3-
S19
GBE1_LINK100#
P20
GBE0_MDI3+
S20
GBE1_MDI1+
P21
GBE0_LINK100#
S21
GBE1_MDI1-
P22
GBE0_LINK1000#
S22
GBE1_LINK1000#
P23
GBE0_MDI2-
S23
GBE1_MDI2+
P24
GBE0_MDI2+
S24
GBE1_MDI2-
P25
GBE0_LINK_ACT#
S25
GND
P26
GBE0_MDI1-
S26
GBE1_MDI3+
P27
GBE0_MDI1+
S27
GBE1_MDI3-
P28
NC
S28
NC
P29
GBE0_MDI0-
S29
NC
P30
GBE0_MDI0+
S30
NC
P31
SPI0_CS1#
S31
GBE1_LINK_ACT#
P32
GND
S32
NC
P33
SDIO_WP
S33
NC
P34
SDIO_CMD
S34
GND
