MSC SM2S-IMX8MINI 22 / 87
User Manual
Measuring point P
The temperature at the defined point on the PCB shall not exceed the temperature range in the following table.
Table 4: Temperature Range
Module Variant
Tpcb_min
Tpcb_max
Module variants with commercial temperature components
0 °C
+70 °C
Module variants with extended temperature components
-25 °C
+ 85 °C
Module variants with industrial temperature components
- 40 °C
+ 85 °C
Figure 2-1: Defined Temperature Point
