MSC SM2S-IMX8MINI 11 / 87
User Manual
1 Introduction
SMARC™ modules are compact, highly integrated Single Board
Computers.
Typically a SMARC™ module consists of a CPU, chipset, memory,
Ethernet controller and USB controller. Interface controllers or
connectors (e.g. RJ45) are implemented on a base board on to which
the SMARC™ module can be mounted.
In addition to the power supply PCIe, USB, etc. interfaces are present
on the connector.
Due to the standardized mechanics and interfaces the system can be
scaled arbitrarily. Despite the modular concept the system design is very
flat and compact.
SMARC™ modules require a carrier board to build a working system.
For evaluation purposes MSC recommends the MSC SM2-MB-EP1
Evaluation Board.
1.1 Key Features
SoC:
• NXP™ i.MX8M Mini ARM® CORTEX™-A53
Assembly options for i.MX8M Mini single, dual or quad-core
SDRAM:
• Up to 4GB LPDDR4
Video:
• Dual Channel LVDS 18-bit/24-bit (1920x1080 max.) or 1x Single Channel LVDS (1366x768 max.) or 1x MIPI-DSI 4 lane (1920x1080 max.)
Audio:
• 2x I²S links for audio codec connection
