Avnet SMARC MSC SM2S-IMX8MINI User Manual

MSC SM2S-IMX8MINI 18 / 87
User Manual
1.4.2 Hardware used
Table 2: Modules used for Power Consumption Measurement
Order
Number
Reference
CPU
RAM
Temp. Range
78402
MSC SM2S-IMX8MINIQC-14N0261I PCBFTX
i.MX8M Mini Quad, Quad-Core Cortex-A53 at 1.8GHz
2G LPDDR4
-40°C to +85°C
78370
MSC SM2S-IMX8MINIQC-13N4200I PCBFTX
i.MX8M Mini Quad, Quad-Core Cortex-A53 at 1.8GHz
2G LPDDR4
-40°C to +85°C
79649
MSC SM2S-IMX8MINIQC-03N0840E PCBFTX
i.MX8M Mini Quad, Quad-Core Cortex-A53 at 1.8GHz
1G LPDDR4
-25°C to +85°C
78368
MSC SM2S-IMX8MINIDC-03N4200I PCBFTX
i.MX8M Mini Dual, Dual-Core Cortex-A53 at 1.8GHz
1G LPDDR4
-40°C to +85°C
78404
MSC SM2S-IMX8MINISC-03N4210I PCBFTX
i.MX8M Mini Solo, Single-Core Cortex-A53 at 1.8GHz
1G LPDDR4
-40°C to +85°C
78406
MSC SM2S-IMX8MINISCL-03N0880I PCBFTX
i.MX8M Mini Solo Lite, Single-Core Cortex-A53 at 1.8GHz
1G LPDDR4
-40°C to +85°C
1.4.3 Measurement Results
Table 3: Typical Power Consumption Measurement
*
Order
Number
Reference
Uboot Idle [W]
Linux idle [W]
Linux Heavy
Load [W]
Deep Sleep [W]
78402
MSC SM2S-IMX8MINIQC-14N0261I PCBFTX
2.045
1.790
4.650
0.315
78370
MSC SM2S-IMX8MINIQC-13N4200I PCBFTX
2.030
1.780
4.610
0.315
79649
MSC SM2S-IMX8MINIQC-03N0840E PCBFTX
1.950
1.710
4.320
0.140
78368
MSC SM2S-IMX8MINIDC-03N4200I PCBFTX
1.905
1.615
3.820
0.350
78404
MSC SM2S-IMX8MINISC-03N4210I PCBFTX
1.810
1.580
3.050
0.310
78406
MSC SM2S-IMX8MINISCL-03N0880I PCBFTX
1.925
1.660
3.046
0.140
*
NOTE: Unless stated otherwise, all measurements were taken at room temperature approx 23°C.
