MSC SM2S-IMX8MINI 12 / 87
User Manual
Camera Interface:
• 1x MIPI CSI-2 2 Lane or 1x MIPI CSI-2 4 Lane *
PCI Express Interface:
• Up to 1x PCIe x1 Gen.2 *
Network:
• Up to 2x 10/100/1000BASE-T Ethernet *
• Optional: H&D Wireless™ Module SPB209A with 802.11 ac/a/b/g/n and Bluetooth 4.2 with BLE support *
USB:
• 1x USB2.0 Host Port with device Interface capability and on-the-go (OTG) support
• 1x USB2.0 Host Port or 4x USB2.0 Host Ports (with additional USB hub populated on module)
GPIO:
• 12x GPIO configurable as input or output (push-pull or open-drain).
SPI:
• 2x SPI with 2 chip selects each *
