Avnet SMARC MSC SM2S-IMX8MINI User Manual

MSC SM2S-IMX8MINI 24 / 87
User Manual
Primary (Top) Side
Secondary (Bottom) Side
P35
SDIO_CD#
S35
USB4+
P36
SDIO_CK
S36
USB4-
P37
SDIO_PWR_EN
S37
NC
P38
GND
S38
AUDIO_MCK
P39
SDIO_D0
S39
I2S0_LRCK
P40
SDIO_D1
S40
I2S0_SDOUT
P41
SDIO_D2
S41
I2S0_SDIN
P42
SDIO_D3
S42
I2S0_CK
P43
SPI0_CS0#
S43
NC
P44
SPI0_CK
S44
NC
P45
SPI0_DIN
S45
NC
P46
SPI0_DO
S46
NC
P47
GND
S47
GND
P48
NC
S48
I2C_GP_CK
P49
NC
S49
I2C_GP_DAT
P50
GND
S50
I2S2_LRCK
P51
NC
S51
I2S2_SDOUT
P52
NC
S52
I2S2_SDIN
P53
GND
S53
I2S2_CK
P54
SPI1_CS0#
S54
NC
P55
SPI1_CS1#
S55
NC
Primary (Top) Side
Secondary (Bottom) Side
P56
SPI1_CK
S56
NC
P57
SPI1_DIN
S57
NC
P58
SPI1_DO
S58
NC
P59
GND
S59
NC
P60
USB0+
S60
NC
P61
USB0-
S61
GND
P62
USB0_EN_OC#
S62
NC
P63
USB0_VBUS_DET
S63
NC
P64
USB0_OTG_ID
S64
GND
P65
USB1+
S65
NC
P66
USB1-
S66
NC
P67
USB1_EN_OC#
S67
GND
P68
GND
S68
USB3+
P69
USB2+
S69
USB3-
P70
USB2-
S70
GND
P71
USB2_EN_OC#
S71
NC
P72
NC
S72
NC
P73
NC
S73
GND
P74
USB3_EN_OC#
S74
NC
S75
NC
KEY
KEY
