USER MANUAL 17
__________________________________________________________________________________________________________________
12.2 Protocol ELTRON description
Transmission parameters: 8 bits, 1 stop bit, no parity, baud rate 9600bps,
 After using key in scale:
 ScaleLabel printer : set of instruction in EPL-2 language that initialize label printing:
US
-
Steering instruction
FR"0001"
-
Label number define instruction
?
-
Instruction that starts list of variable signs
mm:gg
-
5 signs: minutes:hour
rrrr.mm.dd
-
10 signs: year.month.day
masa
-
10 signs: scale indication+ mass unit
P1
-
Steering instruction
Attention:
1. Except variable signs constant signs can also be inscribed e.g. factory name, product name and so
on.
2. In standard only one label pattern is possible to printout (number 0001). Using bigger amount of
patterns (other label numbers) is possible thanks to LAbEL special function.
3. To achieve label printout, label printer must have inscribed label pattern (label pattern is created on
computer and using computer it is saved to label printer memory). Label pattern is designed by
ZEBRA DESIGNER program which is supplied together with label printer.
Scales parameters and transmission protocol must corespond to label printer type.
