Technical Specifications AXIS Panorama PTZ User’s Manual
28
Appendix E - Technical Specifications
System Requirements - TCP/IP support on Windows 95, 98, NT, 2000 or XP. Microsoft
Internet Explorer 4.x, or higher (to use the Axis ActiveX component AXIS Camera Control)
Network Connection - RJ45 twisted pair cable, or remote connection using any standard
serial modem.
Networking - 10baseT Ethernet or 100baseTX Fast Ethernet, TCP/IP, HTTP, FTP, SMTP,
NTP, ARP and BOOTP.
I/O Connector - 1 optical-isolated alarm input. 1 digital output (max 24 V, 100 mA) with
programmable digital input/output for remote image storage via FTP or SMTP, pre/post
alarm image storage.
Pan/Tilt/Zoom - Pan: up to 140
o
. Tilt: up to 65
o
. Zoom; from 0.24x to 4x.
Image Updating - Up to 15 frames/second on 10/100 Mbit networks.
Pre/Post Alarm Buffer - Up to 500 KB memory available for pre/post alarm image storage.
Modem Connector - Single 9-pin D-SUB RS-232 connector, max 115 Kbit/s, half duplex
Operating Conditions: - Temp: 40
o
to 105
o
F (+5
o
to +40
o
C), Humidity: 20-80% RHG.
Approvals - EMC: FCC Class A, EN 55022/1994, EN55024/1998
Safety: EN 60950, UL, CSA.
Metrics (per camera): - Height: 1.6” (4.1 cm), Width: 4.1” (10.5 cm), Length: 6.9” (17.5 cm),
Weight: 0.56 lb. (0.26 kg) excluding power supply.
Hardware - ARTPEC-1 compression chip; ETRAX-100, including, 32-bit RISC, 100 MIPS
CPU, 8 MB RAM, 2 MB FLASH PROM.
Power - External power supply 12 V AC, 9.6 VA (PS-D, included), 9-15 V AC, min. 10 VA,
or 9-15 V DC, min. 7 W.
