Axis W101 User Manual

Axisbodywornsolution
Camerauserguide
1.YoucanchoosetodisabletheFrontbutton(usedtostartandstoprecordings)onthemainbodyworncamera,anduseonlytherecordingbutton
onAXISTW1201BodyWornMiniCubeSensor.Todothis,gotothecameraproleinAXISBodyWornManager.
Note
AXISTW1201BodyWornMiniCubeSensorhasnobuiltinmicrophone.Ifaudiorecordingiscritical,makesurethe
microphoneonthemainbodyworncameraisfreeofanyobstructions.
AXISBodyWornAssistant
AXISBodyWornAssistantisanapplicationthatletsyou:
•viewrecordedvideo
•viewlivevideo
•viewlocationdataforarecording
•categorizeandadddescriptiontorecordedvideoifsupportedbyyourcontentdestination
•accessuserhelp,includingtheDailyUseGuide
YoucandownloadAXISBodyWornAssistantforAndroidandiOS,onGooglePlayandAppStore,respectively.
Note
•Recordedvideocan’tbesavedtoyourmobiledevice.
•ThevisualwatermarkintheimageisonlyvisiblewhenviewingvideoinAXISBodyWornAssistant.Thepurposeofthevisual
watermarkistopreventanyonefromspreadingvideowithoutthepossibilitytotraceitsorigin.
•YoucanviewtherecordingsinAXISBodyWornAssistantupuntilthemomentyoudockthecamera.Afterdocking,the
systemcontrollertransferstherecordingstothecontentdestinationandemptiesthecamera.
ConnectAXISBodyWornAssistanttoabodyworncamera
Note
BeforeyouconnectAXISBodyWornAssistanttoyourbodyworncameraforthersttime,thebodywornsystem
administratormustpairyourbodywornuserwithAXISBodyWornAssistantonthemobiledevice.
1.OpenAXISBodyWornAssistantonyourmobiledevice.
2.TapConnect.
3.Followtheon-screeninstructionsinAXISBodyWornAssistant.
PairabodywornuserwithAXISBodyWornAssistant
TheconnectionbetweenAXISBodyWornAssistantandthebodyworncamerarequiresapairingbetweenthebodywornuserand
AXISBodyWornAssistant.ThepairinginvolvesAXISBodyWornAssistant,AXISBodyWornManager,andthebodyworncamera.The
QRCode®andthePINcodegeneratedbyAXISBodyWornManagerarescannedandenteredinAXISBodyWornAssistantresulting
inasecurepairing.
44

Axis W101 Specifications

General

Sensor type	CMOS
Night vision	-
Fixed focal length	21 mm
Maximum frame rate	30 fps
Maximum resolution	1920 x 1080 pixels
Camera shutter speed	1/32000 - 1/25 s
Minimum illumination	0.1 lx
Vertical field of view	82 °
Viewing angle, horizontal	141 °
Battery capacity	3600 mAh
Power source type	USB
Battery life (max)	17 h
Accelerometer	Yes
Certification	EN 55032 Class B, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class B, ICES-3(B)/NMB-3(B), RCM AS/NZS CISPR 32 Class B EN 300328, EN 301489-1, EN 301489-17, EN 303413, FCC Part 15 Subpart C, RSS-247 IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-78, IEC/EN 60529 IP67 MIL-STD-810H (Method 501.7, 503.7, 505.7, 509.7, 512.6, 516.8)
Video compression formats	AVC, H.264, MPEG4
Housing color	White
Housing material	Plastic
International Protection (IP) code	IP67
Storage temperature (T-T)	-20 - 45 °C
Operating temperature (T-T)	-20 - 55 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 100 %
Connectivity technology	Wireless
Internal storage capacity	64 GB
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1

Weight and Dimensions

Depth	27 mm
Width	68 mm
Height	94 mm
Weight	179 g
