General| Sensor type | CMOS |
|---|---|
| Night vision | - |
| Fixed focal length | 21 mm |
| Maximum frame rate | 30 fps |
| Maximum resolution | 1920 x 1080 pixels |
| Camera shutter speed | 1/32000 - 1/25 s |
| Minimum illumination | 0.1 lx |
| Vertical field of view | 82 ° |
| Viewing angle, horizontal | 141 ° |
| Battery capacity | 3600 mAh |
| Power source type | USB |
| Battery life (max) | 17 h |
| Accelerometer | Yes |
| Certification | EN 55032 Class B, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class B, ICES-3(B)/NMB-3(B), RCM AS/NZS CISPR 32 Class B EN 300328, EN 301489-1, EN 301489-17, EN 303413, FCC Part 15 Subpart C, RSS-247 IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-78, IEC/EN 60529 IP67 MIL-STD-810H (Method 501.7, 503.7, 505.7, 509.7, 512.6, 516.8) |
| Video compression formats | AVC, H.264, MPEG4 |
| Housing color | White |
| Housing material | Plastic |
| International Protection (IP) code | IP67 |
| Storage temperature (T-T) | -20 - 45 °C |
| Operating temperature (T-T) | -20 - 55 °C |
| Storage relative humidity (H-H) | 5 - 95 % |
| Operating relative humidity (H-H) | 10 - 100 % |
| Connectivity technology | Wireless |
| Internal storage capacity | 64 GB |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Bluetooth version | 4.1 |
Weight and Dimensions| Depth | 27 mm |
|---|---|
| Width | 68 mm |
| Height | 94 mm |
| Weight | 179 g |
