Axminster AW10BSB2 - Illustration and Parts Description

Illustration and Parts Description
32
1
2
3
10
3A
50
52
39
51
53
25
32
21
11
13
20
51A
51B
Extension lock
1. Saw Bench
25. Micro Adjuster Assembly
2. Front and Side Panels
26. Extension Tables
3. Lower Leg Columns
27. Table Support Leg
3A. Kickplate
28. Threaded Rubber Foot
4. Dust Extraction Moulding 100mm 32. Long Rip Fence (front rail)
6. Extension Table 33. Long Rip Fence (back rail)
7. Extension Support Brackets 38. Work Clamp and Tool Post
10. Hand Wheels 39. Sliding Table Assembly
11. Mitre Fence 50. Sliding Table Rail Assembly
13. Saw Guard 51. Mitre Angle Rip Fence Assembly
14. Riving Knife 51A. Mitre Angle Rear Quadrant
17. 30mm Hose 51B. Table Fence Mounting Casting
20. Rip Fence Assembly 52. Height Adjusting Block
21. Rip Fence Extension 53. Distance Stop
