30
Chapter 6. Specifications
Item CMS9500 CMS0002 CMS0005
Display
unit
Flow display
4-digit 7-segment LED (the instantaneous ow rate and totalized ow displays can be switched)
Instantaneous
flow rate
Min. display 1 mL/min 0.01 L/min (0.005 L/min)*
8
0.01 L/min
Resolution 1 mL/min 0.01 L/min (0.005 L/min)*
8
0.01 L/min
Totalized
ow
Display unit 10 mL 1 L
Display range 0 to 99999999
Data storage Data is written to memory every 10 minutes. (The totalized ow can be reset by the
keys or external contact input.)
Status display Instantaneous ow rate LED indicator, totalized ow LED indicator, event LED indicators
Output signal (instantaneous
flow rate output)
If 0-5 or 1-5 V DC is selected: Allowable load resistance 250 kΩ min.
Even if the measurement range is exceeded, output
remains less than 6 V.
If 4-20 mA DC is selected: Allowable load resistance 300 Ω max.
Even if the measurement range is exceeded, output
remains less than 24 mA.
Output scaling*
9
Selection of 0–100, 0–200,
0–300, and 0–500 mL/min.
Default setting: 0–500 mL/min
Selection of 0–0.2, 0–0.5,
0–1, and 0–2 L/min.
Default setting: 0–2 L/min
Selection of 0–1, 0–2, 0–3,
and 0–5 L/min
Default setting: 0–5 L/min
Event
output
Outputs 2
Output Open collector (absolute maximum ratings: 30 V DC, 50 mA)
Totalizer pulse output
pulse width
100 ms ±10 %
Totalizer pulse output weight 10, 100, or 1000 mL per pulse 1, 10, or 100 L per pulse
External
contact
input
Inputs 1 (totalized ow count reset input)
Input specications Circuit type of other device: Non-voltage contacts or open collector
Terminal voltage (contacts OFF): 4.5 ±1 V
Terminal current (contacts ON): approx. 0.5 mA (current to contacts)
Allowable ON contact resistance: 250 Ω max.
Allowable OFF contact resistance: 100 kΩ min.
Allowable ON residual voltage: 0.8 V max. (for open collector)
Allowable OFF leakage current: 50 μA max. (for open collector)
Gas type switching Air/nitrogen, argon, carbon dioxide (CO
2
), oxygen (for oxygen models only), fuel gas
13A (46 MJ), 100 % methane, 100 % propane, 100 % butane, and fuel gas 13A (45 MJ)
(selectable by the device keys)
User-specified gas type setup A gas type conversion factor from 0.100 to 8.000 can be specied using the keys.
Electrical connection Harness with dedicated connector (sold separately)
Connector: DF-11-10DS-2C made by Hirose Electric Co. Ltd.
Standards compliance EN 61326-2-3:2013, EN 61326-1:2013
(To be used in an industrial electromagnetic environment)
During EMC testing, the reading or output may uctuate by the equivalent of ±20 % FS.
Weight Approx. 800 g
*1. Gas types other than those listed above can be handled by using a conversion factor. For details, contact the azbil
Group.
*2. For fuel gas 13A, the device is calibrated based on the following two types of gases. If the composition of the fuel gas
that you use does not match either of these types, please contact Azbil Corporation.
Gas type (the following names are used by Azbil Corporation) Methane (%) Ethane (%) Propane (%) Butane (%)
Fuel gas 13A — 46 MJ 88 5.8 4.5 1.7
Fuel gas 13A — 45 MJ 88.9 6.8 3.1 1.2
*3. The ow rate range is for air. Because this device has a gas-type switching function, the device keys can be used to
switch from one gas type to another.
For the maximum measurable ow rate and output voltage for various gas types,
Maximum measurable ow rate
and output voltage for various gas types (P.32).
In addition, analog output scaling can be changed by using the keys.
