Chapter 9. LIST OF COMMUNICATION DATA
Bank
Item name
RAM address EEPROM address RAM EEPROM
Decimal
point
information
Notes
Decimal
Hexadecimal
Decimal
Hexadecimal
Read Write Read Write
DI
Assignment
Internal Contact 1 Polarity A
5407 151F 21791 551F —
Internal Contact 1 Polarity B
5408 1520 21792 5520 —
Internal Contact 1 Polarity C
5409 1521 21793 5521 —
Internal Contact 1 Polarity D
5410 1522 21794 5522 —
Internal Contact 1 Polarity
5411 1523 21795 5523 —
Internal Contact 1 Internal event
No. assignment
5412 1524 21796 5524 —
Internal Contact 2 Operation type
5413 1525 21797 5525 —
Internal Contact 2 Input bit operation
5414 1526 21798 5526 —
Internal Contact 2 Input assignment A
5415 1527 21799 5527 —
Internal Contact 2 Input assignment B
5416 1528 21800 5528 —
Internal Contact 2 Input assignment C
5417 1529 21801 5529 —
Internal Contact 2 Input assignment D
5418 152A 21802 552A —
Internal Contact 2 Polarity A
5419 152B 21803 552B —
Internal Contact 2 Polarity B
5420 152C 21804 552C —
Internal Contact 2 Polarity C
5421 152D 21805 552D —
Internal Contact 2 Polarity D
5422 152E 21806 552E —
Internal Contact 2 Polarity
5423 152F 21807 552F —
Internal Contact 2 Internal event
No. assignment
5424 1530 21808 5530 —
Internal Contact 3 Operation type
5425 1531 21809 5531 —
Internal Contact 3 Input bit operation
5426 1532 21810 5532 —
Internal Contact 3 Input assignment A
5427 1533 21811 5533 —
Internal Contact 3 Input assignment B
5428 1534 21812 5534 —
Internal Contact 3 Input assignment C
5429 1535 21813 5535 —
Internal Contact 3 Input assignment D
5430 1536 21814 5536 —
Internal Contact 3 Polarity A
5431 1537 21815 5537 —
Internal Contact 3 Polarity B
5432 1538 21816 5538 —
Internal Contact 3 Polarity C
5433 1539 21817 5539 —
Internal Contact 3 Polarity D
5434 153A 21818 553A —
Internal Contact 3 Polarity
5435 153B 21819 553B —
Internal Contact 3 Internal event
No. assignment
5436 153C 21820 553C —
Internal Contact 4 Operation type
5437 153D 21821 553D —
Internal Contact 4 Input bit operation
5438 153E 2182 553E —
Internal Contact 4 Input assignment A
5439 153F 2182 553F —
Internal Contact 4 Input assignment B
5440 1540 21824 5540 —
Internal Contact 4 Input assignment C
5441 1541 21825 5541 —
Internal Contact 4 Input assignment D
5442 1542 21826 5542 —
Internal Contact 4 Polarity A
5443 1543 21827 5543 —
Internal Contact 4 Polarity B
5444 1544 21828 5544 —
Internal Contact 4 Polarity C
5445 1545 21829 5545 —
Internal Contact 4 Polarity D
5446 1546 21830 5546 —
Internal Contact 4 Polarity
5447 1547 21831 5547 —
Internal Contact 4 Internal event
No. assignment
5448 1548 21832 5548 —
Internal Contact 5 Operation type
5449 1549 21833 5549 —
Internal Contact 5 Input bit operation
5450 154A 21834 554A —
Internal Contact 5 Input assignment A
5451 154B 21835 554B —
Internal Contact 5 Input assignment B
5452 154C 21836 554C —
Internal Contact 5 Input assignment C
5453 154D 21837 554D —
Internal Contact 5 Input assignment D
5454 154E 21838 554E —
