Parts Identification
Wood Components
(NOT TO SCALE)
M27 - WALL RAIL - W4L09083
5/
8"x3 3/8"x10 3/4" (16x86x274)
(1)
M28 - CLEAT - W4L11232
5/8"x3 3/8"x5 1/4" (16x86x132)
(2)
M47 - PICKET - 51 - W4L11233
5/
8"x3 3/8"x25 1/4" (16x86x640)
(6)
M49 - PICKET - 53 - W4L11234
5/8"x3 3/8"x20 3/8" (16x86x518)
(53)
M73 - REAR SUPPORT - W4L11417
5/8"x3 3/8"x20 1/8" (16x86x512)
(1)
M110 - ATTACHMENT BOARD - W4L11450
5/8"x3 3/8"x20 1/8" (16x86x512)
(1)
N1 - WALL BOARD - W4L11235
5/8"x2 3/8"x32" (16x60x812)
(1)
N2 - WINDOW TRIM - W4L09059
5/8"x2 3/8"x30" (16x60x761)
(1)
N3 - WINDOW TRIM - W4L09081
5/8"x2 3/8"x22 1/2" (16x60x570)
(1)
N4 - WINDOW TRIM - W4L09080
5/
8"x2 3/8"x19 7/8" (16x60x504)
(2)
N5 - WINDOW TRIM - W4L09058
5/8"x2 3/8"x14" (16x60x356)
(2)
N6 - WALL BOARD - W4L11236
5/8"x2 3/8"x10 3/8" (16x60x264)
(2)
M26 - WALL RAIL - W4L09082
5/
8"x3 3/8"x11 1/8" (16x86x284)
(1)
M25 - WALL BOARD - W4L11231
5/8"x3 3/8"x14 1/4" (16x86x362)
(5)
M24 - WALL RAIL - W4L09056
5/8"x3 3/8"x16" (16x86x406)
(1)
M23 - LADDER RUNG - W4L09099
5/8"x3 3/8"x16 7/8" (16x86x429)
(1)
M22 - LADDER RUNG - W4L09101
5/
8"x3 3/8"x22 1/2" (16x86x572)
(11)
M21 - LADDER RUNG - W4L09102
5/8"x3 3/8"x22 1/2" (16x86x572)
(1)
