Parts Identification
Wood Components
(NOT TO SCALE)
M10 - WALL BOARD - W4L11223
5/
8"x3 3/8"x41 1/8" (16x86x1044)
(2)
M11 - WALL RAIL - W4L09055
5/8"x3 3/8"x39 7/8" (16x86x1012)
(1)
M12 - WALL BOARD - W4L11224
5/
8"x3 3/8"x36" (16x86x914)
(6)
M13 - WALL BOARD - W4L11225
5/8"x3 3/8"x36" (16x86x914)
(20)
M14 - WALL BOARD - W4L11226
5/8"x3 3/8"x31" (16x86x788)
(2)
M15 - WALL BOARD - W4L11227
5/8"x3 3/8"x31" (16x86x788)
(2)
M16 - WALL RAIL - W4L09092
5/8"x3 3/8"x27 3/4" (16x86x706)
(4)
M17 - WALL RAIL - W4L09095
5/8"x3 3/8"x26 7/8" (16x86x682)
(2)
M18 - FLOOR BOARD - W4L11228
5/
8"x3 3/8"x24 3/4" (16x86x628)
(16)
M19 - FLOOR BOARD - W4L11229
5/8"x3 3/8"x23 1/8" (16x86x586)
(24)
M20 - FLOOR BOARD - W4L11230
5/8"x3 3/8"x23 1/8" (16x86x586)
(1)
M4 - FLOOR BOARD - W4L11219
5/
8"x3 3/8"x76 3/4" (16x86x1950)
(11)
M5 - FLOOR BOARD - W4L11220
5/8"x3 3/8"x53" (16x86x1346)
(14)
M6 - FLOOR BOARD - W4L11221
5/
8"x3 3/8"x53" (16x86x1346)
(16)
M7 - WALL RAIL - W4L09054
5/8"x3 3/8"x63 1/4" (16x86x1608)
(1)
M8 - WALL RAIL - W4L09085
5/8"x3 3/8"x51 3/4" (16x86x1314)
(4)
M9 - WALL BOARD - W4L11222
5/8"x3 3/8"x45 1/8" (16x86x1146)
(2)
