Parts Identification
Wood Components
(NOT TO SCALE)
L5 - WALL BOARD - W4L11212
5/8
"x4 3/8"x36" (16x112x914)
(2)
L6 - CORNER BOARD - W4L11111
5/8
"x4 3/8"x31" (16x112x788)
(1)
L7 - CORNER BOARD - W4L11213
5/8"x4 3/8"x31" (16x112x788)
(1)
L8 - CORNER BOARD - W4L11214
5/8"x4 3/8"x31" (16x112x788)
(1)
L9 - CORNER BOARD - W4L11215
5/8"x4 3/8"x31" (16x112x788)
(2)
L10 - WALL BOARD - W4L11216
5/8"x4 3/8"x23 3/4" (16x112x602)
(4)
L11 - WALL BOARD - W4L11217
5/8"x4 3/8"x20 3/8" (16x112x518)
(1)
L12 - CORNER BOARD - W4L11218
5/8
"x4 3/8"x41 1/2" (16x112x1055)
(1)
M2 - WALL RAIL - W4L09088
5/8"x3 3/8"x90 1/8" (16x86x2288)
(2)
K97 - GABLE BOARD - W4L11206
3/8
"x3 3/8"x11 3/8" (11x86x288)
(2)
K98 - GABLE BOARD - W4L11207
3/8"x3 3/8"x5" (11x86x126)
(2)
L1 - WALL BOARD - W4L11208
5/8
"x4 3/8"x54 1/4" (16x112x1378)
(1)
L2 - WALL BOARD - W4L11209
5/8"x4 3/8"x45 1/8" (16x112x1146)
(2)
L3 - CORNER BOARD - W4L11210
5/8"x4 3/8"x41 1/2" (16x112x1055)
(1)
L4 - WALL BOARD - W4L11211
5/8"x4 3/8"x41 1/8" (16x112x1044)
(2)
