Parts Identification
Wood Components
(NOT TO SCALE)
K14 - WALL RAIL - W4L09068
5/8
"x5 1/4"x11 5/8" (16x134x294)
(1)
K15 - WALL RAIL - W4L09067
5/8
"x5 1/4"x11 5/8" (16x134x294)
(1)
K16 - SAFETY RAIL - W4L11199
5/8"x5 1/4"x16 7/8" (16x134x430)
(1)
K91 - GABLE BOARD - W4L11200
3/8"x3 3/8"x49 5/8" (11x86x1260)
(2)
K92 - GABLE BOARD - W4L11201
3/8"x3 3/8"x43 1/4" (11x86x1098)
(2)
K93 - GABLE BOARD - W4L11202
3/8"x3 3/8"x36 7/8" (11x86x936)
(2)
K94 - GABLE BOARD - W4L11203
3/8"x3 3/8"x30 1/2" (11x86x774)
(2)
K95 - GABLE BOARD - W4L11204
3/8
"x3 3/8"x24 1/8" (11x86x612)
(2)
K96 - GABLE BOARD - W4L11205
3/8"x3 3/8"x17 3/4" (11x86x450)
(2)
K8 - WALL RAIL - W4L09097
5/8
"x5 1/4"x27 1/8" (16x134x690)
(2)
K9 - WALL RAIL - W4L09096
5/8"x5 1/4"x26 7/8" (16x134x682)
(2)
K10 - ARCHED RAIL - W4L09094
5/8
"x5 1/4"x25 7/8" (16x134x658)
(2)
K11 - ARCHED RAIL - W4L09098
5/8"x5 1/4"x25 7/8" (16x134x658)
(1)
K12 - FLOOR BOARD - W4L11198
5/8"x5 1/4"x23 1/8" (16x134x586)
(1)
K13 - WALL RAIL - W4L09071
5/8"x5 1/4"x14 1/8" (16x134x360)
(2)
