Parts Identification
Wood Components
(NOT TO SCALE)
J1 - PORCH RAFTER - W4L11197
1"x
2 3/8"x38 1/8" (24x60x969)
(2)
K1 - DOUBLE ARCHED RAIL - W4L09079
5/8
"x5 1/4"x90 1/8" (16x134x2288)
(1)
K2 - WALL RAIL - W4L09060
5/8"x5 1/4"x55 5/8" (16x134x1414)
(1)
K3 - ARCHED RAIL - W4L09047
5/8"x5 1/4"x55 5/8" (16x134x1414)
(1)
K4 - ARCHED RAIL - W4L09045
5/8"x5 1/4"x55 5/8" (16x134x1414)
(1)
K5 - WALL RAIL - W4L09061
5/8"x5 1/4"x54 1/4" (16x134x1378)
(1)
K6 - ARCHED RAIL - W4L09046
5/8
"x5 1/4"x54 1/4" (16x134x1378)
(1)
K7 - ARCHED RAIL - W4L09048
5/8"x5 1/4"x54 1/4" (16x134x1378)
(1)
H76 - LADDER RUNG - W4L06609
1"x
3 3/8"x18 1/8" (24x86x460)
(5)
H22 - WALL RAIL - W4L09050
1"x
3 3/8"x78" (24x86x1982)
(1)
H23 - SUPPORT BOARD - W4L11452
1"x3 3/8"x6 1/4" (24x86x160)
(2)
H24 - FLOOR JOIST - W4L11451
1"x
3 3/8"x53 3/4" (24x86x1366)
(1)
J2 - SAFETY RAIL - W4L09075
1"x2 3/8"x52 1/4" (24x60x1326)
(1)
J3 - SAFETY RAIL - W4L09065
1"x2 3/8"x50 1/2" (24x60x1282)
(1)
J4 - SAFETY RAIL - W4L09074
1"x2 3/8"x52" (24x60x1322)
(1)
J5 - SAFETY RAIL - W4L09070
1"x2 3/8"x53 3/4" (24x60x1366)
(1)
