Parts Identification
Wood Components
(NOT TO SCALE)
H11 - ROOF RAFTER - W4L11192
1"x
3 3/8"x43 7/8" (24x86x1114)
(4)
H14 - FLOOR SUPPORT - W4L11193
1"x
3 3/8"x35 3/8" (24x86x898)
(1)
H15 - FLOOR JOIST - W4L11194
1"x3 3/8"x35 3/8" (24x86x898)
(3)
H8 - FLOOR SUPPORT - W4L09064
1"x
3 3/8"x53" (24x86x1346)
(1)
H9 - FLOOR SUPPORT - W4L09072
1"x3 3/8"x53" (24x86x1346)
(1)
H10 - SUPPORT BOARD - W4L09062
1"x3 3/8"x53" (24x86x1346)
(1)
H12 - WALL RAIL - W4L09057
1"x3 3/8"x38 3/4" (24x86x983)
(1)
H13 - WALL RAIL - W4L09049
1"x3 3/8"x36 1/4" (24x86x922)
(1)
H16 - WALL RAIL - W4L09053
1"x
3 3/8"x26 1/4" (24x86x668)
(1)
H17 - WALL RAIL - W4L09052
1"x3 3/8"x23 3/4" (24x86x604)
(1)
H18 - SEAT - W4L11195
1"x3 3/8"x49 7/8" (24x86x1266)
(1)
H19 - SUPPORT BOARD - W4L11196
1"x3 3/8"x5 1/4" (24x86x132)
(1)
H20 - WALL RAIL - W4L09051
1"x
3 3/8"x92" (24x86x2336)
(1)
H21 - ANGLE BRACE - W4L11112
1"x3 3/8"x47 1/4" (24x86x1201)
(2)
H5 - FLOOR SUPPORT - W4L09073
1"x
3 3/8"x53 3/4" (24x86x1366)
(2)
H6 - FLOOR JOIST - W4L11191
1"x3 3/8"x53 3/4" (24x86x1366)
(2)
H7 - FLOOR SUPPORT - W4L09069
1"x
3 3/8"x53 3/4" (24x86x1366)
(1)
