TFX-5000 Flow Meters for Pipes 2.5 in. and Larger
DQ
-
G
- - - - - - -
XX
- - -
TFX-5000 Ultrasonic Clamp-On Meter DQ
General Area US/Canada, CE G
Medium pipe, 2.5 in. (65 mm) or larger RZ
Medium pipe, submersible, 2.5 in. (65 mm) or larger
1
WZ
2.5…6 inches (65…150 mm) Easy Rail (not available with conduit) JZ
2.5…12 inches (65…300 mm) Easy Rail (not available with conduit) KZ
Medium pipe, high temperature (not available with conduit)
HZ
Large pipe, 8 in. (200 mm) or larger LZ
Large pipe, submersible, 8 in. (200 mm) or larger
1
YZ
110/220V AC Remote Mounted R
24V DC/AC Remote Mounted B
Display and Keypad S
No Display/Keypad W
15 feet (4.5 m) AC
30 feet (9 m) AF
50 feet (15 m) AK
75 feet (23 m) AR
100 feet (30 m) BW
150 feet (46 m) BK
200 feet (61 m) DW
250 feet (76 m) DK
300 feet (90 m) EW
Conduit Type and Length (Conduit length is less than or equal to cable length.)
None WW
5 feet (1.5 m) AA
15 feet (4.5 m) AC
30 feet (9 m) AF
50 feet (15 m) AK
75 feet (23 m) AR
100 feet (30 m) BW
150 feet (46 m) BK
200 feet (61 m) DW
250 feet (76 m) DK
300 feet (90 m) EW
1/2 in. NPT Threads, Poly cable glands S
1/2 in. NPT Threads, Nickel Plated Brass cable glands T
1/2 in. NPT Threads, no cable glands N
M20 Threads, Poly cable glands C
M20 Threads, Nickel Plated Brass cable glands D
M20 Threads, no cable glands A
None XX
Standard Output (Modbus RTU or BACnet MS/TP field selectable) S
Standard Output plus Modbus TCP Ethernet T
Standard Output plus EtherNet/IP U
Standard Output plus BACnet/IP Ethernet V
Standard Output plus Aux Output 9
Units of Measure Totalizer/Flow Rate
Gallons/gallons per minute (field selectable, additional options available) G
Factory Calibrated F
Factory Calibrated/Stainless Steel Tag S
Submersible transducer cables use two conduit openings.
Part Number Construction
Page 55 October 2019 TTM-UM-02222-EN-04
