PARAMETER DESCRIPTIONS BY MENU
Main Menu Structure
The transmitter’s firmware has a hierarchical menu structure. See "Menu Map" on page22 for a visual path to the parameters.
The five Main Menus used in the transmitter firmware are as follows:
Menu Function
SETUP Contains all of the configuration parameters for initially programming the transmitter to measure flow
DISPLAY Configures transmitter display functions
INFORMATION Displays system information, such as the model number and firmware version
DIAGNOSTICS Displays system status and allows you to clear the history, reset to factory defaults and reboot the system
RESET Resets the flow total or unlatches alarms
The following pages define the configuration parameters located in each of the menus.
Setup > Units
Use SETUP > UNITS to define the measurement standards for the transmitter. Contains all of the configuration parameters for
setting the units and decimals for the readings and the totalizer mode. Requires operator level passcode or higher if security
is enabled.
An asterisk (*) indicates the parameter default.
Units Submenus Options/Descriptions
FLOW UNITS
Select the flow rate units/interval displayed on the Home Screen. FLOW UNITS are automatically converted into
the selected option.
Option Units/Interval Option Units/Interval
Fluid BBL/D Fluid Barrels/Day (31.5 Gal) GAL/S US Gallons/Second
IBBL/D Imperial Fluid Barrels/Day (36 IG) GAL/MIN US Gallons/Minute
L/S Liters/Second GAL/H US Gallons/Hour
L/MIN Liters/Minute MG/D Million US Gallons/Day
L/H Liters/Hour IG/S Imperial Gallons/Second
M/S Cubic Meters/Second IG/MIN Imperial Gallons/Minute
M/MIN Cubic Meters/Minute IG/H Imperial Gallons/Hour
M/H Cubic Meters/Hour MIG/D Million Imperial Gallons/Day
FT/S Cubic Feet/Minute OIL BBL/D Oil Barrels/Day (42 Gal)
FT/MIN Cubic Feet/Minute AC-FT/D Acre Feet/Day
FT/H Cubic Feet/Hour
Custom
This selection in only available if Custom Units is enabled through SoloCUE Flow Device
Manager. Use SoloCUE to change the Custom Units.
FLOW DECIMALS This is a numeric entry for the number of decimal places to display. Default is 2. Options are 0…7
FLOW TOTAL MODE
*GROSS FLOW
FORWARD FLOW
REVERSE FLOW
NET FLOW
Any ow in forward and reverse direction.
Forward ow minus reverse ow. A negative total results when reverse ow is greater than
forward ow.
Parameter Descriptions by Menu
Page 23 October 2019 TTM-UM-02222-EN-04
