Units Submenus Options/Descriptions
FLOW TOTAL UNITS
Select the units for the flow total displayed on the Home Screen. FLOW TOTAL UNITS are automatically converted
into the selected option:
Option Units Option Units
GAL US Gallons Fluid BBL Fluid Barrel (31.5 Gal)
MGAL Million US Gallons L Liter
IGAL Imperial Gallons HL Hectoliter
AC-FT Acre Foot M Cubic Meters
MIGAL Million Imperial Gallons FT Cubic Feet
Oil BBL Oil Barrels (42 Gal)
Custom
This selection in only available if Custom Units is enabled through SoloCUE Flow Device
Manager. Use SoloCUE to change the Custom Units.
FLOW TOTAL DECIMALS This is a numeric entry for the number of decimal places to display. Default is 0. Options are 0…7.
VELOCITY UNITS
Select the units for the velocity displayed on the Home Screen.
*FT/S Feet/Second
M/S Meters/Second
ENERGY RATE UNITS
(Energy Units Only)
Select the units for the energy rate displayed on the Home Screen. ENERGY RATE UNITS are automatically
converted into the selected option:
Option Units Option Units
BTU/H Btu/hour kJ/H Kilojoules/hour
kBTU/H Thousand Btu/hour MJ/H Mega joules/hour
MMBTU/H Million Btu/hour kCAL/H Kilocalories/hour
W Watts MCAL/H Mega calories/hour
*kW Kilowatts
TON (RT)
Ton (Refrigeration)
1 Ton = 12,000 Btu/h
MW Megawatts
ENERGY RATE DECIMAL
(Energy Units Only)
This is a numeric entry for the number of decimal places to display. Default is 2. Options are 0…7.
ENERGY TOTAL MODE
(Energy Units Only)
FORWARD FLOW
REVERSE FLOW
NET FLOW Forward flow minus reverse flow. A negative total results when reverse flow is greater than
the forward flow.
*GROSS FLOW Any flow in forward and reverse direction.
ENERGY TOTAL UNITS
(Energy Units Only)
Select the units for the energy total displayed on the Home Screen. ENERGY TOTAL UNITS are automatically
converted into the selected option:
Option Units Option Units
BTU British Thermal Unit kWH Kilowatt Hour
kBTU Thousand Btu MWh Megawatt Hour
MMBTU Million Btu kJ Kilo Joules
KCAL Kilo Calories MJ Mega Joules
MCAL Mega Calories TON-H Ton-hour (Refrigeration)
ENERGY TOTAL DECIMALS
(Energy Units Only)
This is a numeric entry for the number of decimal places to display. Default is 2. Options are 0…7.
TEMPERATURE UNITS
(Energy Units Only)
°F
°C
K
DISPLAY MODE
Select the parameters to display on the Home Screen. Alternatively, you can change the display from the Home
Screen by pressing the DOWN button.
*FLOW RATE ENERGY TOTAL
FLOW TOTAL TEMP #1 / TEMP #2
VELOCITY ENERGY RATE / DELTA TEMPERATURE
RATE/TOTAL ENERGY RATE / ENERGY TOTAL
ENERGY RATE TIME / DATE
Parameter Descriptions by Menu
Page 24 October 2019TTM-UM-02222-EN-04
