Selecting an Option in a Parameter Selection List
The active option in the parameter list has a filled-in box on the left side. The scroll bar on the right indicates the relative
position the cursor bar is at on the list when there are more than 4 items.
• DOWN ARROW scrolls the list.
• ENTER selects the option and the box on the left side fills in to show the item is selected.
• MENU/BACK exits parameter editing and returns to the parent menu (up a level).
Entering a Number
The parameter name and current value is displayed in the top portion of the screen. Edit the number on the bottom right of
the screen.
• MENU/BACK exits parameter editing and returns to parent menu (up a level). The parameter remains at the value displayed
in the top portion of the screen.
• DOWN ARROW cycles through the numbers and other options.
• RIGHT ARROW moves the cursor to the right. Once it reaches the rightmost digit or a space, the cursor moves to the
leftmost digit.
• ENTER accepts the value.
Operation
Page 9 October 2019 TTM-UM-02222-EN-04
