Setup > Meter > Pipe
An asterisk (*) indicates the parameter default.
Pipe Submenus Options/Descriptions
PIPE MATERIAL
STAINLESS 302/303 STAINLESS 430 IRON - DUCTILE POLYPROPYLENE
STAINLESS 304 ALUMINUM HD POLYETHYLENE
STAINLESS 304L BRASS NAVAL LD POLYETHYLENE
*STAINLESS 316 CARBON STEEL PFA TEFLON
STAINLESS 347 COPPER PVC CPVC
STAINLESS 410 IRON - CAST PVDF
PIPE TYPE
For the best accuracy, measure the outer diameter and wall thickness with a gauge and select MANUAL INCHES
or MANUAL MM.
If you do not have a gauge, you can select an ASME/ANSI or ASTM definition. Schedule, copper tubing and cast
iron class are filtered based on pipe material selection.
If stainless steel pipe, carbon steel, cvc, pcvc material is selected, the following pipe schedules are also available
as applicable:
SCHEDULE STD SCHEDULE 80
SCHEDULE 5 SCHEDULE 100
*SCHEDULE 10 SCHEDULE 120
SCHEDULE 20 SCHEDULE 140
SCHEDULE 30 SCHEDULE 160
SCHEDULE 40 SCHEDULE 180
SCHEDULE 60 SCHEDULE STG
If copper material is selected, the following types are also available:
TYPE K TYPE M
TYPE L PIPE SIZE
If cast iron pipe material is selected, the following classes are also available:
CLASS A CLASS E
CLASS B CLASS F
CLASS C CLASS G
CLASS D CLASS H
If ductile iron pipe material is selected, the following classes are also available:
CLASS 50 CLASS 54
CLASS 51 CLASS 55
CLASS 52 CLASS 56
CLASS 53
If aluminum or brass naval material is selected, the following is also available:
PIPE SIZE (in inches)
PIPE SIZE Available only when PIPE TYPE is MANUAL; Numeric entry; min. 0.5 in (15 mm), max. 300 in (7500 mm)
PIPE SIZE NOMINAL
PIPE SIZE NOMINAL is substituted for PIPE SIZE when a schedule/tubing/class is selected.
Enumeration based on schedule; min. 0.5 in. (15 mm), max. 24 in. (610 mm)
1/2, 3/4, 1, 1-1/4, 1-1/2, 2, 2-1/2, 3, 3-1/2, 4, 6, 8, 10, 12, 14, 16, 18, 20, 24
WALL THICKNESS
Numeric entry; *min. 0.00, max. 5 in. (125 mm);
WALL THICKNESS is only useful for MANUAL METRIC and MANUAL INCHES; It can be skipped for pipe schedule,
tubing and classes
LINER MATERIAL
NONE HD POLYETHYLENE TAR EPOXY
ACRYLIC LD POLYETHYLENE PFE TEFLON
ASBESTOS CEMENT POLYPROPYLENE GLASS PYREX
EBONITE POLYSTYRENE FIBERGLASS EPOXY
MORTAR RUBBER
LINER THICKNESS Numeric entry; min. 0.00, max. 5 in. (125 mm)
I.D. SIZE Numeric display in inches or millimeters, based on PIPE TYPE
Parameter Descriptions by Menu
Page 26 October 2019TTM-UM-02222-EN-04
