Setup > Meter
Contains all of the configuration parameters for setting the meter. Requires service level passcode or higher if security is
enabled. An asterisk (*) indicates the parameter default.
Meter Submenus Options/Descriptions
TRANSDUCER
Select the transducer type:
UZ 2 MHZ Option UZ when ordered with the TFX-5000 meter
CX 2 MHZ Options CA…CS and CZ when ordered with the TFX-5000 meter
JZ / KZ EASYRAIL 1 MHZ Options JZ and KZ when ordered with the TFX-5000 meter
NZ / RZ / WZ 1 MHZ Options NZ, WZ and RZ when ordered with the TFX-5000 meter
HZ 1 MHZ Option HZ when ordered with the TFX-5000 meter
LZ / YZ 0.5 MHZ Option LZ when ordered with the TFX-5000 meter
MOUNTING
For mounting options, see the transducer user manual.
Z PATH
*V PATH
W PATH
Cx TYPE
DTTC TYPE is substituted for MOUNTING when TRANSDUCER DTTC is selected as the transducer type.
CA: 1/2 IN ANSI CJ: 1-1/4 IN COPPER
CB: 3/4 IN ANSI CK: 1-1/2 IN COPPER
CC: 1 IN ANSI CL: 2 IN COPPER
CD: 1-1/4 IN ANSI CM: 1/2 IN SS TUBE
CE: 1-1/2 IN ANSI CN: 3/4 IN SS TUBE
CF: 2 IN ANSI CP: 1 IN SS TUBE
CG: 1/2 IN COPPER CQ: 1-1/4 IN SS TUBE
CH: 3/4 IN COPPER CR: 1-1/2 IN SS TUBE
CT: 1 IN COPPER CS: 2 SS IN TUBE
