Badger Meter ModMAG M2000 User Manual

M2000 memory map by register address Page 18/30
MID_M2000_BA_MODBUS_02_1805
Register address
Register name
Register type
0x00FD
ADC interrupt counter
UINT16
0x00FE
ADC range counter
UINT16
0x00FF
WDT resets counter
UINT16
0x0100
WDT location
UINT16
0x0101
System error #
UINT16
0x0102
Reserved
UINT16
0x0103
Reserved
UINT16
0x0104
Reserved
UINT16
0x0105
Reserved
UINT16
0x0106
Meter status
UINT16
0x0107
Power loss totalizer [seconds]
UINT32
0x0109
Achtion request overflows
UINT16
0x010A
Measurement overflows
UINT16
0x010B
Scale factor [%]
FLOAT32
0x010D
Zero scale flow [user units]
FLOAT32
0x010F
Display backlight mode
UINT16
0x0110
Preset batch amount [m
3
]
FLOAT32
0x0112
Menu reset allowed
UINT16
0x0114
Menu language settings
UINT16
0x0115
Analog input measure value
FLOAT32
0x0117
File system – Numer ov records to read
UINT16
0x0118
Port B extended address
UINT16
0x0119
Analog input measure counter
UINT16
0x011A
Empty pipe actual resistance [ohms]
FLOAT32
0x011C
Security status
UINT16
0x011D
Configuration status
UINT16
0x011E
Empty pipe calibration [volts]
FLOAT32
0x0120
Empty pipe measure value [volts]
FLOAT32
0x0122
Full pipe calibration [volts]
FLOAT32
0x0124
Empty pipe mode
UINT16
0x0125
Command action request
UINT16
0x0126
Analog output calibration point A [A]
FLOAT32
0x0128
Analog output calibration point B [A]
FLOAT32
0x012A
Flow simulation
SINT16
0x012B
Random value
UINT32
0x012D
Flow direction
UINT16
0x012E
Alarm mode
UINT16
0x012F
Remote login
UINT32
0x00C3
Port A: Framing errors
UINT16
0x00C4
Port A: Overrun errors
UINT16
0x00C5
Port A: Break detects
UINT16
0x00C6
Port B: Packets processed
UINT16
0x00C7
Port B: Broadcast packets
UINT16
0x00C8
Port B: CRC errors
UINT16

Badger Meter ModMAG M2000 Specifications

General

Flow Measurement Technology	Electromagnetic
Enclosure Rating	NEMA 4X (IP66)
Repeatability	±0.1% of rate
Output	4-20 mA, pulse, frequency
Display	LCD with backlight
Power Supply	100 to 240 VAC or 24 VDC
Communication Protocols	HART, Modbus
Process Connection	Flanged, Threaded
Electrode Material	316 Stainless Steel, Hastelloy, Tantalum
Liner Material	PTFE, PFA, Polyurethane
Accuracy	±0.2% of rate
Temperature Range	-40°...160°F (-40°...71°C)
Fluid Temperature	-4°...302°F (-20°...150°C)
Materials	Stainless Steel, Carbon Steel
