Badger Meter ModMAG M2000 User Manual

M2000 memory map by register address Page 20/30
MID_M2000_BA_MODBUS_02_1805
Register address
Register name
Register type
0x0131
Analog output slope
FLOAT32
0x0133
Analog customer offset 4 mA [A]
FLOAT32
0x0135
Analog customer offset 20 mA[A]
FLOAT32
0x0137
T1 /T+ Display string
UCHAR16 [8]
0x013F
T2 /T- Display string
UCHAR16 [8]
0x0147
T3 /TN Display string
UCHAR16 [8]
0x014E
Analog output current [A]
FLOAT32
0x0150
Analog output current string [mA]
UCHAR16 [4]
0x0154
Remote resets
UINT16
0x0155
Digital input: Status
UINT16
0x0156
Power on splash line 2
UCHAR16 [11]
0x0161
Meter tag name
UCHAR16 [17]
0x0172
Reserved (to addr 0x01FF)
UINT16 [142]

Badger Meter ModMAG M2000 Specifications

General

Flow Measurement Technology	Electromagnetic
Enclosure Rating	NEMA 4X (IP66)
Repeatability	±0.1% of rate
Output	4-20 mA, pulse, frequency
Display	LCD with backlight
Power Supply	100 to 240 VAC or 24 VDC
Communication Protocols	HART, Modbus
Process Connection	Flanged, Threaded
Electrode Material	316 Stainless Steel, Hastelloy, Tantalum
Liner Material	PTFE, PFA, Polyurethane
Accuracy	±0.2% of rate
Temperature Range	-40°...160°F (-40°...71°C)
Fluid Temperature	-4°...302°F (-20°...150°C)
Materials	Stainless Steel, Carbon Steel
