M2000 register write properties Page 22/30
MID_M2000_BA_MODBUS_02_1805
No Register name
Register
address
Min.
value
Max.
value
Value definition
** Req.
Action
request
26
Detector current [mA]
0x007D
100
400
--
YES
28
Power line frequency
[Hz]
0x0081 0 1
0 =50 Hz
1 = 60 Hz
YES
29
Excitation frequency
[Hz]
0x0082 0 3
0 = 1 Hz
1 = 3.125 Hz or 3.75 Hz
2 = 6.25 Hz or 7.5 Hz
3 = 12.5 hz or 15 Hz
YES
30
Scale factor [%]
0x010B
-10
10
--
YES
31 Flow unit 0x0083 0 18
0 = LPS
1 = LPM
2 = LPH
3 = M
3
S
4 = M
3
M
5 = M
3
H
6 = F
3
S
7 = F
3
M
8 = F
3
H
9 = GPS
10 = GPM
11 = GPH
12 = MGD
13 = IPS
14 = IPM
15 = IPH
16 = LBM
17 = OZM
18 = BPM
YES
32 Volume unit 0x0084 0 10
0 = Liter
1 = Hectoliters
2 = Cubic meters
3 = Cubic feet
4 = US gallons
5 = Mega gallons
6 = UK gallons
7 = Pounds
8 = Ounces
9 = Acre feet
10 = Barrels
YES
** Command action code 0x01 should be issued to the command action request register
immediately following any non – volatile register uptdate**

Badger Meter ModMAG M2000 Specifications

General

Flow Measurement Technology	Electromagnetic
Enclosure Rating	NEMA 4X (IP66)
Repeatability	±0.1% of rate
Output	4-20 mA, pulse, frequency
Display	LCD with backlight
Power Supply	100 to 240 VAC or 24 VDC
Communication Protocols	HART, Modbus
Process Connection	Flanged, Threaded
Electrode Material	316 Stainless Steel, Hastelloy, Tantalum
Liner Material	PTFE, PFA, Polyurethane
Accuracy	±0.2% of rate
Temperature Range	-40°...160°F (-40°...71°C)
Fluid Temperature	-4°...302°F (-20°...150°C)
Materials	Stainless Steel, Carbon Steel
