Badger Meter ModMAG M2000 User Manual

M2000 register write properties Page 23/30
MID_M2000_BA_MODBUS_02_1805
No Register name
Register
address
Min.
value
Max.
value
Value definition
** Req.
Action
request
33 Unit multiplier 0x0085 0 32771
0 = Off
1 = 1 unit
10 = 10 units
100 = 100 units
1000 = 1000 units
10000 = 10000 units
32768 = 0.1 units
32769 = 0.01 units
32770 = 0.001 units
32771 = 0.0001 units
YES
34
Zero scale flow
[user units]
0x010D 0
10 % of
full scale
-- YES
35
Full scale velocity
[m/s]
0x0086 0 12 -- YES
36
Full scale flow
[user units]
0x0090 0 Variable --
YES
37
Low flow cutoff [%]
0x008E
0
9.9
--
YES
38 Flow direction 0x0092 0 1
0 = uni-directional
1 = bi-directional
YES
39 Damping factor [s] 0x0093 0 30
0 = 0 second
1 = 1 second
2 = 2 seconds
3 = 3 seconds
4 = 4 seconds
5 = 5 seconds
10 = 10 seconds
20 = 20 seconds
30 = 30 seconds
YES
40
Digital input:
Input operation
0x0094 0 3
0 = Off
1 = Remote reset
2 = Positive zero return
3 = Batch reset
YES
42
Analog output
range
0x0095 1 4
1 = 4…20 mA
2 = 0…20 mA
3 = 0…20 mA
4 = 2…20 mA
YES
** Command action code 0x01 should be issued to the command action request register
immediately following any non – volatile register uptdate**

Badger Meter ModMAG M2000 Specifications

General

Flow Measurement Technology	Electromagnetic
Enclosure Rating	NEMA 4X (IP66)
Repeatability	±0.1% of rate
Output	4-20 mA, pulse, frequency
Display	LCD with backlight
Power Supply	100 to 240 VAC or 24 VDC
Communication Protocols	HART, Modbus
Process Connection	Flanged, Threaded
Electrode Material	316 Stainless Steel, Hastelloy, Tantalum
Liner Material	PTFE, PFA, Polyurethane
Accuracy	±0.2% of rate
Temperature Range	-40°...160°F (-40°...71°C)
Fluid Temperature	-4°...302°F (-20°...150°C)
Materials	Stainless Steel, Carbon Steel
