M2000 register write properties Page 24/30
MID_M2000_BA_MODBUS_02_1805
No Register name
Register
address
Min.
value
Max. value Value definition
** Req.
Action
request
44
Analog output
calibration point A [A]
0x0126 0 0.024 -- YES
45
Analog output
calibration point B [A]
0x0128 0 0.024 -- YES
49
Analog customer
offset 4 mA [A]
0x0133 0 0.024 -- YES
50
Analog customer
offset 20 mA [A]
0 0.024 YES
53 Alarme mode 0x012E 0 2
0: Meter error has no
influence on analog
output
1: Meter error drives
output 2 mA below
minimum range
2: Meter error drives
output 2 mA above
maximum range
YES
54
Fixed current mode
0x008A
0
20
--
YES
55
Output #1:
Pulses per unit [m
3
]
0x0098 0 9999999.999 --
YES
56
Output #1:
Pulses per unit
[user unit]
0x009C 0 9999999.999 -- YES
57
Output #1:
Pulse width [ms]
0x00A0 0 9999 0 = 50 % duty cycle
YES
58
Output #1:
Flow alarm minimum
[%]
0x00A1 0 100
1 = 1%
100 = 100%
YES
59
Output #1:
Flow alarm maximum
[%]
0x00A2 0 100
1 = 1%
100 = 100%
YES
60
Output #1:
Output mode
0x00A3 0 1
0 = Normally open
1 = Normally closed
YES
** Command action code 0x01 should be issued to the command action request register immediately
following any non – volatile register uptdate**

Badger Meter ModMAG M2000 Specifications

General

Flow Measurement Technology	Electromagnetic
Enclosure Rating	NEMA 4X (IP66)
Repeatability	±0.1% of rate
Output	4-20 mA, pulse, frequency
Display	LCD with backlight
Power Supply	100 to 240 VAC or 24 VDC
Communication Protocols	HART, Modbus
Process Connection	Flanged, Threaded
Electrode Material	316 Stainless Steel, Hastelloy, Tantalum
Liner Material	PTFE, PFA, Polyurethane
Accuracy	±0.2% of rate
Temperature Range	-40°...160°F (-40°...71°C)
Fluid Temperature	-4°...302°F (-20°...150°C)
Materials	Stainless Steel, Carbon Steel
