Badger Meter ModMAG M2000 User Manual

M2000 register write properties Page 25/30
MID_M2000_BA_MODBUS_02_1805
No Register name
Register
address
Min.
value
Max. value Value definition
** Req.
Action
request
61
Output #1:
Output operation
0x00A4 0 11
0 = Off
1 = Flow alarm
2 = Empty pipe alarm
3 = Error alarm
4 = Forward pulse
5 = AMR pulse
6 = Reverse pulse
7 = Frequency output
8 = Preset batch output
9 = Flow direction
10 = Verification test
11 = 24V DC supply
62
Output #2:
Pulses per unit [m
3
]
0x00A5 0 9999999.999 -- YES
63
Output #2:
Pulses per unit
[user unit]
0x00A9 0 9999999.999 -- YES
64
Output #2:
Pulse width [ms]
0x00AD 0 9999 0 = 50 % duty cycle
YES
65
Output #2:
Flow alarm
minimum [%]
0x00AE 0 100
1 = 1%
100 = 100%
YES
66
Output #2:
Flow alarm
maximum [%]
0x00AF 0 100
1 = 1%
100 = 100%
YES
67
Output #2:
Output mode
0x00B0 0 1
0 = Normally open
1 = Normally closed
YES
68
Output #2:
Output operation
0x00B1 0 11
0 = Off
1 = Flow alarm
2 = Empty pipe alarm
3 = Error alarm
4 = Forward pulse
5 = AMR pulse
6 = Reverse pulse
7 = Frequency output
8 = Preset batch output
9 = Flow direction
10 = Verification test
11 = 24V DC supply
YES
** Command action code 0x01 should be issued to the command action request register
immediately following any non – volatile register uptdate**

Badger Meter ModMAG M2000 Specifications

General

Flow Measurement Technology	Electromagnetic
Enclosure Rating	NEMA 4X (IP66)
Repeatability	±0.1% of rate
Output	4-20 mA, pulse, frequency
Display	LCD with backlight
Power Supply	100 to 240 VAC or 24 VDC
Communication Protocols	HART, Modbus
Process Connection	Flanged, Threaded
Electrode Material	316 Stainless Steel, Hastelloy, Tantalum
Liner Material	PTFE, PFA, Polyurethane
Accuracy	±0.2% of rate
Temperature Range	-40°...160°F (-40°...71°C)
Fluid Temperature	-4°...302°F (-20°...150°C)
Materials	Stainless Steel, Carbon Steel
