INTRODUCTION
GLOSSARY OF TERMS AND ABBREVIATIONS (continued)
1 - 6 I-E96-207A
®
GLOSSARY OF TERMS AND ABBREVIATIONS
(continued)
REFERENCE DOCUMENTS
NOMENCLATURE
Term Definition
SAC
Station for Analog Control. Provides monitoring and allows manipulation of a
single process control loop, and communicates with the MFP. It has front
panel LED bar graphs that display set point, process variable and control
output values.
Slave Expander
Bus
Parallel address/data bus between the master module and the slave.
TM
Termination Module; provides input/output connection between plant equip-
ment and the INFI 90 process modules. The termination module slides into a
slot in the termination mounting unit.
TU
Termination Unit; provides input/output connection between plant equipment
and the INFI 90 process modules. The termination unit is a flat circuit board
for panel mounting.
Document
Number
Document
I-E96-117 Analog Control Station (IISAC01)
I-E96-506 Module Mounting Unit (IEMMU01/02/04)
I-E96-423 Control I/O Termination Unit (NTCS02)
I-E96-409 Control I/O Termination Module (NICS01)
I-E93-911 Station Termination Module (NIDS01)
Nomenclature Hardware
IEMMU01
IEMMU02
IEMMU04
Module Mounting Unit
IISAC01 Analog Control Station
NICS01 Control I/O Termination Module
NIDS01 Station Termination Module
NTCS02 Control I/O Termination Unit
