Bailey INFI 90 IMCOM03 - Advanced Control Functions

CONFIGURATION
FUNCTION CODES
4 - 6 I-E96-207A
®
Compute Logic
1 Function Generation
3 Lead/Lag
5Pulse Rate
6 High/Low Limit
7 Square Root
8 Rate Limit
13 Integer Transfer
14 Sum - 4 Inputs
15 Sum - 2 Inputs
16 Multiply
17 Divide
58 Time Delay, Analog
65 4 Input Digital Sum with Gain
33 Not
34 Remote Control Memory
35 Time Delay, Digital
36 Qualified OR (8 input)
37 AND - 2 Inputs
38 AND - 4 Inputs
39 OR - 2 Inputs
40 OR - 4 Inputs
85 Up/Down Counter
Signal Status
12 High Alarm/Low Alarm
31 Test Quality
69 Test Alarm
Signal Select I/O - Module Bus
9 Transfer, Analog
10 High Select
11 Low Select
13 Transfer, Integer
59 Transfer, Digital
25 Analog Input/Bus
28 Analog Output/Bus
41 Digital Input/Bus
63 Analog Input List/Bus
64 Digital Input List/Bus
I/O - Field I/O - Communication Highway
27 Analog Input/TCS
29 Analog Output/TCS
43 Digital Input/TCS
44 Digital Output/TCS
26 Analog Input/Loop
30 Analog Output/Loop (Exception Report)
42 Digital Input/Loop
45 Digital Output/Loop
Basic functions apply to the IMCOM03 and IMCOM04.
Table 4-2. Advanced Control Functions
No. Function Code Definition No. Function Code Definition
152 Model Parameter Estimator
153 ISC Parameter Converter
154 Adaptive Parameter Controller
156 Advanced PID Controller
157 General Digital Controller
160 Smith Predictor
161 Sequence Generator
162 Segment Buffer/Digital
163 Segment Buffer/Analog
164 Segment Control Block
165 Moving Average
166 Integrator
167 Polynomial Equation1
168 2 Dimensional Interpolation Integrator
169 3 x 3 Matrix Add
170 Multiply Sequence Generator
(3X#3 Matrix Multiply)
171 Trigonometric Functions
172 Y
x
, e
x
(Exponential)
173 Power
174 Ln x, log x (Logarithm)
Advanced functions apply to the IMCOM04.
Table 4-1. Basic Control Functions
(continued)
No. Function Code Definition No. Function Code Definition
