TERMINATION UNIT CONNECTIONS
6 - 4 I-E96-207A
®
TERMINATION UNIT CONNECTIONS
Table 6-5 lists the P3 connections on the controller module (P1
connections on the termination Unit).
Table 6-5. P1 Pin Connections (NTCS02)
Cable Connections
1. Digital Output 1-
3. Digital Output 2-
5. Digital Output 3-
7. Digital Output 4-
2. Digital Output 1+
4. Digital Output 2+
6. Digital Output 3+
8. Digital Output 4+
13. Serial Link -
17. Digital Input 1-
19. Digital Input 2-
21. Digital Input 3-
16. Serial Link +
18. Digital Input 1+
20. Digital Input 2+
22. Digital Input 3+
23. +24 VDC
25. Analog Output 1-
27. Analog Output 2-
29. Analog Input 1-
24. No Connection
26. Analog Output 1+
28. Analog Output 2+
30. Analog Input 1+
31. Analog Input 2-
33. Analog Input 3-
35. Analog Input 4-
32. Analog Input 2+
34. Analog Input 3+
36. Analog Input 4+
NOTE:
14 is the TU Cable Shield.
Table 6-6. Terminal Block Assignments
TB1-10
TB1-9
TB1-8
TB1-7
TB1-6
AI 1+
AI 1-
AO 1+
AO 1-
M/A 1 COMMON
TB3-10
TB3-9
TB3-8
TB3-7
TB3-6
AI 3-
AI 3-
DO 3+
DO 3-
DO 4+
TB1-5
TB1-4
TB1-3
TB1-2
TB1-1
M/A 1 SELECT
M/A 1 POWER
LOWER 1
R/L 1 COMMON
RAISE 1
TB3-5
TB3-4
TB3-3
TB3-2
TB3-1
DO 4-
DI 3+
DI 3-
+24 VDC (fused)
COMMON
TB2-10
TB2-9
TB2-8
TB2-7
TB2-6
AI 2+
AI 2-
DO 1+
DO 1-
DO 2+
TB4-10
TB4-9
TB4-8
TB4-7
TB4-6
AI 4+
AI 4-
AO 2+
AO 2-
M/A 2 COMMON
TB2-5
TB2-4
TB2-3
TB2-2
TB2-1
DO 2-
DI 1+
DI 1-
DI 2+
DI 2-
TB4-5
TB4-4
TB4-3
TB4-2
TB4-1
M/A 2 SELECT
M/A 2 POWER
LOWER 2
R/L 2 COMMON
RAISE 2
Legend:
DI-Digital Input AO-Analog Output
R/L-Raise/Lower M/A-Manual/Auto (Final Device Drive Status)
AI-Analog Input A-Analog or Pulse Input
DO-Digital Output M-Raise Lower Contact Input
