INSTALLATION
PREOPERATING ADJUSTMENTS
3 - 10 I-E96-207A
®
Figure 3-5. IMCOM03/04 Cable Connections and Termination
T00117A
P1
P1
P3 P1
P3 P1
P2
P2
NKTM01
OR
NKTU02
NICS01IMCOM03/04
NTCS02IMCOM03/04
NKTU01
4 ANALOG INPUTS
(1-5 VDC, 4-20 mA)
3 DIGITAL INPUTS
(24/125 VDC)
4 ANALOG INPUTS
(1-5 VDC, 4-20 mA)
3 DIGITAL INPUTS
(24/125 VDC)
2 ANALOG OUTPUTS
(1-5 VDC, 4-20 mA)
4 DIGITAL OUTPUTS
(24 VDC AT 250 mA)
2 ANALOG OUTPUTS
(1-5 VDC, 4-20 mA)
4 DIGITAL OUTPUTS
(24 VDC AT 250 mA)
