TERMINATION UNIT CONFIGURATION (NTCS02)
INTRODUCTION
I-E96-207A A - 3
Table A-1. Input/Output Dipshunt Configuration
Application Dipshunts
Configuration
1 2 3 4 5 6 7 8
ANALOG INPUTS 1 through 4
Powered 4-20 mA Input
Unpowered 4-20 mA Input
Single-Edged Voltage Input
Differential Voltage Input
XU1-XU4
1 0 1 0 0 1 1 1
0 1 0 1 0 1 0 1
0 1 0 1 0 0 1 1
0 1 0 1 1 0 0 0
ANALOG OUTPUTS
Both Outputs in Voltage Mode
Analog Output 1 = Voltage
Analog Output 2 = Current
Analog Output 1 = Current
Analog Output 2 = Voltage
Both Outputs in Current Mode
XU9
1 1 0 0 0 0 1 1
1 1 0 0 0 0 0 0
0 0 0 0 0 0 1 1
0 0 0 0 0 0 0 0
DIGITAL INPUTS 1 through 3
+24 VDC I/O Supply in Series
Separate 24 VDC/125 VDC
Supply in Series
Field Powered Input (External)
XU5-XU7
0 0 0 0 1 0 1 0
1 0 1 0 0 0 0 0
0 0 0 0 0 0 0 1
ANALOG INPUT FEEDBACK
Both Digital Stations
Digital Station 1
Digital Station 2
XU8
1 1 0 1 1 0 0 0
1 1 0 0 0 1 0 0
0 0 1 1 1 0 0 0
DIGITAL OUTPUTS NONE N/A
NOTE:
0 - Cut strap, 1 - Strap intact
