TERMINATION UNIT CONFIGURATION (NTCS02)
INTRODUCTION
A - 6 I-E96-207A
®
Figure A-3. Analog Input Dipshunt Configurations (continued)
T00123A
+24 V
(I/O POWER)
FIELD
XMTTR
DIPSHUNTS XU1-XU4 CONTROLLER INPUT CIRCUITRY
161
152
143
134
125
11
6
107
98
DIFFERENTIAL VOLTAGE INPUT
+
–
TERMINAL
BLOCK
–
+
MUX
+24 V
(I/O POWER)
FIELD
XMTTR
DIPSHUNTS XU1-XU4 CONTROLLER INPUT CIRCUITRY
161
152
143
134
125
11
6
107
98
SINGLE-ENDED VOLTAGE INPUT
+
–
TERMINAL
BLOCK
–
+
MUX
