MN1957 Input / Output 4-1
Input / Output
4 Input / Output
4.1 Introduction
This section describes the input and output capabilities of the NextMove ESB-2.
The following conventions will be used to refer to the inputs and outputs:
I/O . . . . . . . . . . . . . . Input / Output
DIN . . . . . . . . . . . . . Digital Input
DOUT . . . . . . . . . . . Digital Output
AIN . . . . . . . . . . . . . Analog Input
AOUT . . . . . . . . . . . Analog Output
