MN1957 Specifications 7-1
Specifications
7 Specifications
7.1 Introduction
This section provides technical specifications of the NextMove ESB-2.
7.1.1 Input power
7.1.2 Analog inputs
7.1.3 Analog outputs
Description Value
Input power
Nominal input voltage
Power consumption
24 VDC (±20%)
50 W (2 A @24 V approx.)
Description Unit Value
Type Differential
Common mode voltage range VDC ±10
Input impedance kΩ 120
Input ADC resolution bits 12 (includes sign bit)
Equivalent resolution (±10 V input) mV ±4.9
Sampling interval μs 500 (both inputs enabled)
250 (one input disabled)
Description Unit Value
Type Bipolar
Output voltage range VDC ±10
Output current (per output) mA 2.5
Output DAC resolution bits 12
Equivalent resolution mV ±4.9
Update interval μs 100 - 2000
(same as LOOPTIME; default = 1000)
