Baldor NextMove ESB-2 User Manual

4-4 Input / Output MN1957
www.baldormotion.com
Figure 3: AIN0 analog input wiring
Figure 4: Typical input circuit to provide 0-10 V (approx.) input from a 24 V source
AIN0+ AIN0+
11
X12 X12
22
AIN0 AIN0
()ADC.0 ()ADC.0
Differential connection Single ended connection
33
AIN0-
GND
+24VDC
1
X12
2
AIN0
()ADC.0
3
0V
1 k , 0.25 W
potentiometer
Ù
1.5 k , 0.25 WÙ
